Fits perfectly on FALK 1000 GL sandwich panels and FALK profiled sheets
FALK 1000 GL double-walled, clear roofing panel for daylight, to be used in combination with corrugated sandwich panels or profiled sheets. The clear roofing panel is exceptionally strong and retains its shape.
Clear roofing panel with corrugated profile
The FALK 1000 GL clear roofing panel is a transparent corrugated panel with the FALK 1000 GL profile. It has a height of 40mm and a centre-to-centre distance of 167mm. These sheets have been specifically designed for roofs fitted with FALK sandwich panels or profiled sheets.
Double-walled polycarbonate panel
These clear roof panels are double-walled, so they are strong and retain their shape. Although the maximum length is 8 metres, our advice is not to order more than 5 metres; this is because polycarbonate can work under different weather conditions. The panels have a fire rating of B-s1,d0 and are finished with a film that does not discolour and acts as a UV barrier for optimum light transmission.
Light transmittance
The clear roof panel is available in two colours, opal and clear. The opal version is a milky colour and a light transmittance of 40%; the clear model is completely transparent and has a light transmittance of around 74%. Both panels help to create a healthy working and living environment.
Core thickness [mm]
R-value [m²K/W]
Weight [kg/m²]
Fire class
3.0
0.26
Ca. 2.5
B-s1,d0
Working width
1100 mm
Center-to-center distance
367 mm
Profile height
30 mm
Minimum length
500 mm
Maximum length
7.000 mm
UV-barrier
The plate is provided with a film, a UV barrier for optimal light and to prevent discolouration.
FALK is the first manufacturer in the world to offer a circular insulated panel. We only have one planet, so we need to use its natural resources wisely. A choice for a FALK insulated roof panel with CradleCore® insulation is a choice for recycling. CradleCore® is a guarantee that we will recycle those panels in the future. This way, raw materials will be available for future generations and you will achieve significant environmental benefits! We have quantified these in an Environmental Product Declaration (EPD). Read all about CradleCore®
In most circumstances, solar panels can be installed on FALK insulated roof panels, but this will depend on the chosen span of the panels and the substructure. Always seek professional advice in order to avoid any potential problems. Special brackets are available that can be mounted on our sandwich panels. For more information, visit our page on solar panels.
